Product Introduction: The Mobile Sand Making Machine is an efficient, eco-friendly mobile crushing equipment integrating crushing, sand making, and screening. Equipped with a tire-mounted mobile chassis, it can quickly move to job sites without complex foundation work, significantly enhancing production efficiency and flexibility. It is ideal for industrial sand making and screening operations in various applications, including ore, concrete, highway, railway, hydropower station construction, and other infrastructure projects.
Applications:
E-mail: joyal@crusherinc.com
| Technical paratameter | ||
| Item | Y3S1860B9532 | |
| model | power(kw) | |
| Raw materials hopper | 10m3 | |
| Vibrating feeder | GZG903 | 0.75kwx2 |
| VSI sand making crusher | VSI-5X-9532 | 160kwx2 |
| Vibrating screen/3decks | 6000x1800 | 22 |
| Feeding belt conveyor (Harden gear) | B800x6M | 5.5 |
| Return belt conveyor (Harden gear) | B800x3M | 5.5 |
| Discharge belt conveyor under vibrating screen (Harden gear) | B650x8M | 4 |
| Discharge belt conveyor (Harden gear) | B800x14M | 7.5 |
| return belt conveyor (Harden gear) | B800x15M | 7.5 |
| Electric control panel | the VSI sand crusher controlled by VFD, all electrical components are sourced from DELIXI, a renowned brand, guaranteeing high - quality and reliable operation. | |
| Capacity(tons/hour) | 180-540 | |
| Total Power(kw) | 373.5 | |
300tph Quartz rock Mobile crushing line in Thailand
100tph Granite stone Mobile crushing line in Paraguay
200TPH Mountain Rock Mobile Crushing Plant in Mozambique
200tph Granite stone Mobile crushing line in Paraguay
40-60tph Mountain Rock Mobile crushing line in Peru
300tph Granite stone Mobile crushing line in Nigeria
